- # of Pockets : Main Module : 4+2
Expansion Module : 2 pocket/unit ｜ Max 12 pockets (6 modules)
- Hopper Capacity : Upto 2000
- Stacker Capacity : 500
- Reject Capacity Reject 1 : 100
Reject 2 : 200
- Normal Count : 1000
- Value Count : 1000
- Fitness : 1000
- S/N Speed : 1000
- Dimension(W/H/D) Main : 731X534X392mm
Expansion(2P) : 276X348X392mm
- Weight Main 55kg ｜ Exp 10kg
- Functions Auto/Mix
Face & Orientation ｜ S/N (OCR) ｜ Fitness
- S/N Reading : Available
- Fitness(F type) : Available
- Currency : INR All Denominations
- Sensor : Dual CIS ｜ UV ｜ MG(18ch) ｜ IR ｜ US
- Connectivity/Interface : Serial Port x 4
LAN x 2 (Normal & Debug)
USB x 1
- OS : Linux
- Screen : 7" Touch Display
(800 x 480 Pixels)
- Expansion Module : Dual Pocket Expansion Structure
Maximum 6 Moules (12 Pockets)
- Options & Special Features : Interactive Pocket Structure
Batch Card support
Support External Data Screen
