IONX-900 - Precision That Builds Trust.
IONX-900 is a compact, advanced XRF Gold Testing Machine designed for fast, non-destructive and highly accurate purity testing, delivering accuracy up to ±0.01%. With a FAST SDD detector and 5–60 second testing, it helps businesses make quicker, smarter valuation decisions.
Ideal for Gold Shops, Gold Loan Companies, Banks, Hallmarking Centres, Pawn Brokers & NBFCs.
Test Faster. Value Smarter. Build Customer Trust.
Compact Size. Exceptional Precision.
High Accuracy
Up to ±0.01%
Compact Size
Maximum Intelligence.
Minimum Space.
Reliable & Durable
Built for continuous
performance
Make in India
Service & support
you can count on
| Performance and Configuration | |
|---|---|
| Analysis Range | ppm–99.99% |
| Accuracy | ±0.01% (Au ≥ 99.9%) |
| Sample | Solid, Powder, Liquid |
| Technical Specifications | |
|---|---|
| High Voltage | 0–50kV / 0–1mA |
| Detector | FAST SDD (Amptek USA) |
| Resolution | 122±5eV |
| X-ray Source | W-target with Be window |
| Collimator | 2mm (Optional 1mm) |
| Chamber Size | 300×300×100mm |
| Test Time | 5–60 sec |
| Detectable Elements | Na (11)–U (92), except light elements |
| Camera | HD Camera |
| Analyzer | Digital Multichannel |
| Software | Parshwa Technologies Qualitative & Quantitative Analysis Software |
| Dimensions | 500×400×300mm |
| Weight | 40kg |
| Environmental Conditions | |
|---|---|
| Temperature | 5–38°C |
| Humidity | 15–90% |
| Power Supply | AC 220V ±5V, 50/60Hz |
| Interference Protection | Avoid electromagnetic & vibration sources |
