IONX-600 - Maximum Precision. Minimum Space.
IONX-600 is a compact, high-performance XRF Gold Testing Machine designed for fast, non-destructive and highly accurate purity testing, with accuracy up to ±0.01%. Its advanced SDD detector, rapid 5–60 second testing and easy operation make it a smart investment for businesses that value precision and trust.
Ideal for Gold Shops, Gold Loan Companies, Banks, Hallmarking Centres, Pawn Brokers & NBFCs.
Test Precisely. Value Confidently. Grow Your Business.
Compact Machine. Exceptional Accuracy.
High Accuracy
Up to ±0.01%
Compact Size
Maximum Intelligence.
Minimum Space.
Reliable & Durable
Built for continuous
performance
Make in India
Service & support
you can count on
| Performance and Configuration | |
|---|---|
| Analysis Range | ppm–99.99% |
| Accuracy | ±0.01% (Au ≥ 99.9%) |
| Sample Form | Solid, Powder, Liquid |
| Technical Specifications | |
|---|---|
| High Voltage | 0–50kV / 0–1mA |
| Detector | SDD (Amptek USA) |
| Resolution | 129±5eV |
| X-ray Source | W-target, Triple Stage Cooling |
| Collimator | 2mm (Optional 1mm) |
| Chamber Size | 400×300×150mm |
| Test Time | 5–60 sec |
| Detectable Elements | Na (11)–U (92), except light elements |
| Camera | HD Camera |
| Analyzer | Digital Multichannel |
| Software | Parshwa Technologies Qualitative & Quantitative Analysis Software |
| Dimensions | 500×400×300mm |
| Weight | 40kg |
| Environmental Conditions | |
|---|---|
| Operating Temperature | 5°C–38°C |
| Humidity | 15%–90% |
| Power Supply | AC 220V ±5V, 50/60 Hz |
| Interference Protection | Low electromagnetic & vibration interference recommended |
